Please Contact Us to Order to offer best price and delivery time for Fristam - p/n: 0444000001 type: FP 742/165 B pump with motor base number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Fristam - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy p/n: 0444000001 type: FP 742/165 B by Fristam in United States?
You can purchase p/n: 0444000001 type: FP 742/165 B by Fristam from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the p/n: 0444000001 type: FP 742/165 B?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Fristam in United States?
While we are not the official distributor or seller of Fristam in United States, we source our products from reliable channels and offer you original Fristam equipment at competitive prices.
How can I access p/n: 0444000001 type: FP 742/165 B catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for p/n: 0444000001 type: FP 742/165 B on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for p/n: 0444000001 type: FP 742/165 B?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
BRAND | Fristam |
Product | p/n: 0444000001 type: FP 742/165 B |
Description | pump with motor base |
Internal code | ONR4606978 |
Custom code | 84137051 |
Technical specification | Pump material: 1.4404 (316L) Shaft seal: 9.665 (2N5E3/2N5E3) 1. coal/cast chrome/EPDM 2. coal/cast chrome/EPDM Elastomers: EPDM alcohol resistant with FDA certification Connection type: DIN 2633 Suction side: DN 65 Pressure side: DN 50 Impeller diameter: 165 mm Engine: 4.0 kW, n = 2900 rpm 50 Hz, ISO class: F Voltage 400/690V IP 55 Certificates/tests: - FDA certificate/EG1935/2004 In general: - Alexis No. 91 paint pure silver engine: - Special motor: 112M motor size with PTC thermistor temperature sensor - according to efficiency class IE3 pumphead: - Connections: flange DIN 2633 Shaft seal: - Mechanical seal: double acting flushing water pressure max. 0.2 bar incl. flushing water connection with pipe G1/8" other agreements: pump as S/N 0444590526, but motor according to IE3 |
