ZBA 71 A 2 B003 - Demag United States Sales

Please Contact Us to Order to offer best price and delivery time for Demag - ZBA 71 A 2 B003 Engine number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Demag - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy ZBA 71 A 2 B003 by Demag in United States?

You can purchase ZBA 71 A 2 B003 by Demag from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the ZBA 71 A 2 B003?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Demag in United States?

While we are not the official distributor or seller of Demag in United States, we source our products from reliable channels and offer you original Demag equipment at competitive prices.

How can I access ZBA 71 A 2 B003 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for ZBA 71 A 2 B003 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for ZBA 71 A 2 B003?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Technical specification

BRAND	Demag
Product	ZBA 71 A 2 B003
Description	Engine
Internal code	ONR4915849
Technical specification	The motor is designed in accordance with DIN EN 60034-1. Note: The selected motor does not fall under the scope of the EuP Directive. Technical data: Motor speed 2750 rpm Power 0.37 kW Operating time 60% Motor protection class IP 54 Ambient temperature -20... +60 °C Installation height ≤ 1000 m Design key ZBA 71 A 2 B003-H-1 Type H Terminal box position on the right, 1 Horizontal motor installation position Total net weight approx. 12 kg Electrical data: Supply voltage D/Y 230/400 V Line frequency 50 Hz Current D/Y 1.70/1.00 A Brake technical data: Braking torque 2.5 Nm Voltage 180 V DC Current 0.11 A with brake rectifier GE 400 V AC equipment: 2 temperature monitors for shutdown at 155 °C with phase insulation for inverter operation with sprocket for direct attachment to DRF200 i=43.70 Light fan disc Oiltight bearing plate selected ambient temperature: 60° C Warmth class F Warmth class F color scheme: RAL 5009, azure blue documentation: Assembly instructions EU documents in accordance with the Machinery Directive
