Please Contact Us to Order to offer best price and delivery time for Michael Riedel Transformatorenbau - REIA 100 isolating transformer number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
default.not_official_distributor_Group5
| BRAND | Michael Riedel Transformatorenbau |
| Product | REIA 100 |
| Description | isolating transformer |
| Internal code | ONR4614187 |
| Technical specification | Primary voltage (PH-PH): AC 400/460 V Primary current: 0.25/0.22 A Secondary voltage (PH-PH): AC 24 V Secondary current: 4.17 A groupset: Ii0 Rated frequency: 50/60 Hz Protection class: SK I (protection class 1) Operating mode: S1 (continuous operation)/100% ED Ambient conditions: 40°C/E Cooling type: ON (normal air convection) Installation height: 1000m above sea level Degree of protection: IPXXB (finger-safe) Primary connection: terminals (screw connection) for 4 mm² Secondary connection: terminals (screw connection) for 4 mm² Earth connection: Faston for 6.3 mm Manufactured and tested according to: VDE 0570-2-6/EN61558-2-6 (safety transformer) Mechanical data: Dimensions (W x D x H): approx. 85 x 82 x 93 mm Mounting dimensions (W x D): 64 x 61 mm, for M4 |
No documents...
power supply
Transformer
Spartrafo
transformer
Transformer
TAX TRANSFORMER
Transformers
Power Supply
transformer
transformer
Initial sample test report
Test report per batch
Test report per piece
