Please Contact Us to Order to offer best price and delivery time for Michael Riedel Transformatorenbau - REIA 2500 EP isolation transformer number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
default.not_official_distributor_Group5
BRAND | Michael Riedel Transformatorenbau |
Product | REIA 2500 |
Description | EP isolation transformer |
Internal code | ONR4725667 |
Custom code | 85043200 |
Technical specification | Name: EP isolation transformer Power: 2 kVA Primary Voltage (PH-PH): AC 480 V Primary current: 4.2 A Secondary Voltage (PH-PH): AC 110V Secondary current: 18.2 A Design frequency: 60 Hz Protection class: SK I (protection class 1) Operating mode: S1 (continuous operation)/100% ED Ambient conditions: 40°C/E Type of cooling: ON (normal air convection) Installation height: 1000m above sea level Protection class: IPXXB (finger safe) Primary connection: terminals (screw connection) for 4 mm² Secondary connection: terminals (screw connection) for 4 mm² Grounding connection: Faston for 6.3 mm Manufactured and tested in accordance with: VDE 0570-2-4/EN61558-2-4 (separating transformer) Mechanical data: Dimensions (W x D x H): approx 195 x 176 x 178 mm Mounting size (W x D): approx. 150 x 144 mm, for M8 |
No documents...
