RDRK 25 - Michael Riedel Transformatorenbau United States Sales

Please Contact Us to Order to offer best price and delivery time for Michael Riedel Transformatorenbau - RDRK 25 DX isolating transformer number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

default.not_official_distributor_Group5

Technical specification

BRAND	Michael Riedel Transformatorenbau
Product	RDRK 25
Description	DX isolating transformer
Internal code	ONR4986260
Technical specification	Power: 0.6 kVA Primary voltage (PH-PH): 3AC 380/440 V (star) +/- 5% tapping Primary current: 1.13/0.98 A Secondary voltage (PH-PH): DC 24V Secondary current: 25 A Rated frequency: 50/60 Hz Protection class: SK I (protection class 1) Operating mode: S1 (continuous operation)/100% ED Ambient conditions: 40°C/E Type of cooling: ON (normal air convection) Installation height: 1000 m above sea level Protection class: IP00 Primary connection: terminals (screw connection) for 4 mm² Secondary connection: terminals (screw connection) for 4 mm² Grounding connection: Faston for 6.3 mm Manufactured and tested in accordance with: VDE 0570-2-6/EN61558-2-6 (safety transformer) Mechanical data: Dimensions (W x D x H): approx. 190 x 190 x 165 mm Mounting dimensions (W x D): 136 x 77 mm, for M6 Miscellaneous: -Vacuum-impregnated -RW < 5%
