Please Contact Us to Order to offer best price and delivery time for AEG - Protect 8.33 number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we AEG - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy Protect 8.33 by AEG in United States?
You can purchase Protect 8.33 by AEG from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the Protect 8.33?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of AEG in United States?
While we are not the official distributor or seller of AEG in United States, we source our products from reliable channels and offer you original AEG equipment at competitive prices.
How can I access Protect 8.33 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for Protect 8.33 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for Protect 8.33?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
BRAND | AEG |
Product | Protect 8.33 |
Internal code | ONR4717715 |
Technical specification | a) Rectifier: Supply voltage: 400 V 15%/3 Ph./PE (adjustable to 3x380 V or 3x 415 V) Power consumption at rated load: 98 A at 400 V Power consumption at rated load and battery charge: 123 A at 400 V Network effects: 6-pulse+ filter Frequency: 50 Hz 10% or 60 Hz 10% DC output voltage: 384 V 20% b) Inverter: Nominal output: 60 kVA (at cos = 0.8 ind.) AC output voltage: 400 V/3 Ph./N/PE Variance, static: 1% Deviation, dynamic: < 2% (in case of load surge 0 - 100% - 0 without network assistance) Frequency: 50 Hz, optional 60 Hz Power factor range: 0 ind. - 1 - 0 kap. Output phase current: 87 A at 400 V Voltage curve shape: sinusoidal Distortion factor: < 3% in total DC voltage, Load and power factor range Non-linear load: up to 100% of the rated UPS capacity Short circuit current L-N 500 ms 3.22 x Inenn Short circuit current 3-phase 500 ms 1.81 x Innn Crest factor: 3, distortion factor where < 3% Overload behavior: 150% for 1 min., 125% for 10 min. c) General data: Supply voltage (EUE): 400 V 10% (adjustable)/3 Ph./N/PE overall efficiency 100% load (PF=0.8): 91.9 ± 2% Radio suppression degree: “A” in accordance with EN 62040-2 Immunity: according to EN 61006-4 Cooling type: reinforced air self-cooling with built-in redundant fans Operating mode: continuous operation Painting: RAL 7035 (powder coating) Protection class: IP20 Dimensions (WxHxD): 750 mm x 1800 mm x 860 mm |
