MI-DL0113 DL1133-AACABB0H9HDB-262mm - Interroll United States Sales

Please Contact Us to Order to offer best price and delivery time for Interroll - MI-DL0113 DL1133-AACABB0H9HDB-262mm number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Interroll - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy MI-DL0113 DL1133-AACABB0H9HDB-262mm by Interroll in United States?

You can purchase MI-DL0113 DL1133-AACABB0H9HDB-262mm by Interroll from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the MI-DL0113 DL1133-AACABB0H9HDB-262mm?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Interroll in United States?

While we are not the official distributor or seller of Interroll in United States, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.

How can I access MI-DL0113 DL1133-AACABB0H9HDB-262mm catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MI-DL0113 DL1133-AACABB0H9HDB-262mm on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MI-DL0113 DL1133-AACABB0H9HDB-262mm?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Technical specification

BRAND	Interroll
Product	MI-DL0113 DL1133-AACABB0H9HDB-262mm
Internal code	ONR4624838
Technical specification	Product name DL1133 IP 66 degree of protection Tube length (SL) 240.0 mm drum width (FW) 262.0 mm Installation length (EL/LW/BF) 268.0 mm Axle total length (AGL) 308.0 mm power 110 W winding number of poles 4 Torque [Nm] 20.1 tape tension 355 N Gear ratio (i) 30.77 speed at frequency 1 0.26 m/s frequency 1 50 Hz external connection diagram E33 high voltage 400 V rated current, high voltage 0.45 A speed at frequency 2 0.32 m/s frequency 2 60 Hz high voltage 2 460 V pipe material stainless steel: 1.4301/304 pipe diameter (A) 113.3 mm tube diameter (B) 112.2 mm tube shape crowned (standard) lid A material stainless steel: 1.4305/303 lid B material stainless steel: 1.4305/303 cap A material stainless steel: 1.4336 /316 cap B material stainless steel: 1.4336 /316 cap A design 60° grease nipple cap B version 60° grease nipple cap A diameter 35.0 mm cap B diameter 35.0 mm cap A key face width 21.0 mm cap B key face width 21.0 mm cap A key face length 20.0 mm cap B key face length 20.0 mm Oil type synthetic food grade oil Electrical connection Butt plate without cable slot Power cable length 1.0 m Power cable type unshielded; non halogen free
