LVU503 - Omega United States Sales

Please Contact Us to Order to offer best price and delivery time for Omega - LVU503 2” NPT Level Transmitter 9.8’ (3M) range, 4 SPST relays, w/ Fob USB Interface number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Omega - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy LVU503 by Omega in United States?

You can purchase LVU503 by Omega from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the LVU503?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Omega in United States?

While we are not the official distributor or seller of Omega in United States, we source our products from reliable channels and offer you original Omega equipment at competitive prices.

How can I access LVU503 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for LVU503 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for LVU503?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Technical specification

BRAND	Omega
Product	LVU503
Description	2” NPT Level Transmitter 9.8’ (3M) range, 4 SPST relays, w/ Fob USB Interface
Internal code	ONR4903665
Technical specification	Range: LVU501: 1.5” to 4.9’ (3.8 cm to 1.5 m), LVU503: 4” to 9.8’ (10.1 cm to 3 m) Accuracy: LVU501: 0.125” (3 mm), LVU503: ± 0.2% of range Resolution: LVU501: 0.019” (0.5 mm), LVU503: 0.039” (1 mm) Deadband: LVU501: 1.5” (3.8 cm), LVU503: 4” (10.1 cm) Beam width: 2” (5 cm) Configuration: WebCal® PC Windows® USB® 2.0 Memory: Non-volatile Supply voltage: 14-28 VDC Max. consumption: 0.5W Loop resistance: 500 ohms @ 24 VDC Signal output: 4-20 mA, two-wire Signal invert: 4-20 mA or 20-4 mA Signal fail-safe: 4 mA, 20 mA, 21 mA, 22 mA, hold last Contact type: (4) SPST relays Contact rating: 60 VA, 1A maximum Contact fail-safe: Open, closed, hold last Contact hysteresis: Selectable Process temp.: F: -40 to 176º, C: -40 to 80º Temp. comp.: Automatic Ambient temp.: F: -31 to 140º, C: -35 to 60º Pressure: 30 psi (2 bar) Enclosure rating: Type 6P (IP68) Encl. material: Polypropylene Transducer type: Reflective Ultrasonic Transducer mat.: Polyvinylidene fluoride Cable jacket mat.: Polyurethane Cable type: 9-conductor, shielded Cable length: 48” (1.2m) Process mount: 2” NPT, or 2” G Mount gasket: 2” G FKM® Classification: General purpose Approval: UL 61010-1 Compliance: CE, RoHS
