OP210014-A31 - Interroll United States Sales

Please Contact Us to Order to offer best price and delivery time for Interroll - OP210014-A31 DM 0080 Asynchronous 3-Phase number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Interroll - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy OP210014-A31 by Interroll in United States?

You can purchase OP210014-A31 by Interroll from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the OP210014-A31?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Interroll in United States?

While we are not the official distributor or seller of Interroll in United States, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.

How can I access OP210014-A31 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for OP210014-A31 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for OP210014-A31?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Technical specification

BRAND	Interroll
Product	OP210014-A31
Description	DM 0080 Asynchronous 3-Phase
Internal code	ONR5055395
Technical specification	Certification cRUus UL Certified IP Rating 69K Shell Length (SL) 11.30 " Face Width (FW) 11.57 " Between Frames (EL/LW/BF) 11.77 " Overall Length (AGL) 12.76 " Poles 2 Power 0.19 hp Torque [Nm] 14.8 Belt Pull Force 364 N Gear Ratio (i) 42.28 Gear Material Steel: 16MnCr5 / AISI 5115 Velocity at Frequency 1 68 fpm Frequency 1 60 Hz External Wiring Diagram M34 High Voltage 460 V Low Voltage 230 V Current, High Voltage 0.37 A Current, Low Voltage 0.63 A Velocity at Frequency 2 56 fpm Frequency 2 50 Hz High Voltage 2 400 V Low Voltage 2 230 V Shell Material Steel: St37-2 / AISI 1015 Shell Diameter (A) 3.21 " Shell Diameter (B) 3.17 " Shell Shape Crowned (Standard) Housing A Feature Standard Housing B Feature Standard Housing A Material ALU: EN-AC43400 / AL239 Housing B Material ALU: EN-AC43400 / AL239 Shaft A Shape Standard Ø30mm Shaft B Shape Standard Ø30mm Shaft A Material Stainl. Steel: 1.4305 / 303 Shaft B Material Stainl. Steel: 1.4305 / 303 Shaft A Flat Width (F) 0.98 " Shaft B Flat Width (F) 0.98 " Shaft A Flat Length (C) 0.49 " Shaft B Flat Length (C) 0.49 " Oil Type Mineral Oil Viscosity 68 Electrical Connection Straight Connector Electrical Connection Material Brass: CuZn39Pb3 / MS58 Power Cable Length 3.0 m Power Cable Type Non Screened; Non Halogen Free Min Ambient Temperature 2 °C Max Ambient Temperature 40 °C MI-DM0080 DM0803-AAA0BD0U0KJC-294mm
