DIC-4-150-E0000-03 - Demag United States Sales

Please Contact Us to Order to offer best price and delivery time for Demag - DIC-4-150-E0000-03 Inverter number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Demag - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy DIC-4-150-E0000-03 by Demag in United States?

You can purchase DIC-4-150-E0000-03 by Demag from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the DIC-4-150-E0000-03?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Demag in United States?

While we are not the official distributor or seller of Demag in United States, we source our products from reliable channels and offer you original Demag equipment at competitive prices.

How can I access DIC-4-150-E0000-03 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for DIC-4-150-E0000-03 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for DIC-4-150-E0000-03?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Technical specification
Document

BRAND	Demag
Product	DIC-4-150-E0000-03
Description	Inverter
Internal code	ONR1133997
Weight	45
Technical specification	Line voltage: 3 x 380 - 480 V (+10/-15%) Line frequency: 50/60 Hz (+10/-10%) Motor shaft power: 75.00 kW output voltage: 3 x 0 - line voltage V Output frequency: 0 - 300 Hz depending on switching frequency Output current: 150.0 A at 2 to 8kHz Overload factor at 2 and 4 kHz: 1.5 for 60 s; 1.8 for 10 s (cycle 10 min) Modulation frequency: 2, 4, 8 kHz (current reduction at 8 Pay attention to kHz) Protection class: IP 20 Operating temperature: 0 - 40 °C Installation height: 0 - 1000 m Dimensions: 412/510/351 mm width/height/depth Installation position: vertical Net weight approx.: 45.0 kg Technical data at the operating point Supply voltage: 3 x 400 V output current: 150.0 A at 40°C ambient temperature and 4 kHz modulation frequency Overload factor: 1.5 for 60 s (cycle 10 min.) 1.8 for 10 s (cycle 10 min.) Operating temperature: 0 °C/40 °C Installation height: 0/1000 m specification: Tipo: Dedrive Compact STO DIC-4-150-E-0000-03 - Keypad KP 500 (control unit) - CM RS 232 communication module - Data cable (PC <-> CM RS 232 or KP 232/length: 1.8 m) - Braking resistor for a lifting application Technical data: 1 x FAQU 3248004-4 ohms - 40 kW - Overcurrent relay - EM UNI-01 extension module with: - Encoder input, configurable to 2 digital inputs - Digital port (digital input/output - Motor paltleiter connection - analog output - analog input (bipolar) - Semiconductor relay with potential-free closing contact (for switching AC control voltage) - CAN system bus - PWM control module (PWM analog 0-10V)
