Please Contact Us to Order to offer best price and delivery time for Michael Riedel Transformatorenbau - RDRKN 30K Sonder Power Supply number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
default.not_official_distributor_Group5
BRAND | Michael Riedel Transformatorenbau |
Product | RDRKN 30K Sonder |
Description | Power Supply |
Internal code | ONR4948086 |
Technical specification | Name: DX isolating transformer Power: 0.72 kVA -------------------------- Primary voltage (PH-PH): 3AC 420/440/460 V (star) Primary current: 1.32/1.26/1.21 A Secondary voltage (PH-PH): DC 24V Secondary current: 30 A Rated frequency: 50/60 Hz Protection class: SK I (protection class 1) Operating mode: S1 (continuous operation)/100% ED Ambient conditions: 40°C/E Type of cooling: ON (normal air convection) Installation height: 1000 m above sea level Protection class: IPXXB (finger safe) Primary connection: terminals (screw connection) for 4 mm² Secondary connection: terminals (screw connection) for 10 mm² Grounding connection: terminals (screw connection) for 4 mm² Manufactured and tested in accordance with: VDE 0570-2-6/EN61558-2-6 (safety transformer) Mechanical data: Dimensions (W x D x H): approx. 206 x 200 x 160 mm Mounting dimensions (W x D): 184 x 120 mm, for M6 |
No documents...
