24SPRE50 - AEG United States Sales

Please Contact Us to Order to offer best price and delivery time for AEG - 24SPRE50 Thyristor controlled industrial rectifier & battery charger number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we AEG - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy 24SPRE50 by AEG in United States?

You can purchase 24SPRE50 by AEG from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the 24SPRE50?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of AEG in United States?

While we are not the official distributor or seller of AEG in United States, we source our products from reliable channels and offer you original AEG equipment at competitive prices.

How can I access 24SPRE50 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 24SPRE50 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 24SPRE50?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Technical specification
Document

BRAND	AEG
Product	24SPRE50
Description	Thyristor controlled industrial rectifier & battery charger
Internal code	ONR3424585
Weight	160
Technical specification	DC UPS Protect RCS 24V / 50A System configuration System setup Single Operation Battery configuration Individual battery The Protect RCS DC UPS System is a microprocessor based thyristor controlled rectifier. It provides high quality DC power for electronic equipment loads. Mechanical specification Enclosure free standing metal suitable for floor mounting type V2000 cabinet Metal sheet thickness Frame 2 mm Panels 1.5 mm Door 2 mm Protection class (according to IEC 60529) IP21 Painting RAL7035 Ventilation Air inlet in the front doors, front and back cabinet bottom, outlet through rear panel on the top Acoustic noise <66 dB(A) Cable entry from Bottom Dimensions: Height 1200 mm Width 600 mm Depth 800 mm Weight approx. 160 kg Electrical specification Rectifier type: 2 pulse (SCR) thyristor Nominal input voltage 230 VAC Input voltage tolerance ±10% Exceptional variation of the mains input voltage +15%, 20% Number of phases 1 Input frequency 50 Hz Input frequency tolerance ±6% Max. input current (10% mains, in high rate charge and Inom on the output) 13 A AC Rectifier input current total harmonic distortion (THDi) < 66% Input power at nominal voltage and float charge 0,64 Nominal DC output voltage 24V DC Nominal DC output current 50A DC Voltage regulation Static: ±1% • at float charge • 0 100% DC load variation • input mains voltage within the range ±10% • input frequency within the range ±6% • battery temperature within 0°C to 40°C Dynamic: With single LC filter with a battery connected (capacity >5 x nominal current of the rectifier • load variation 10% => 90% : 5% • load variation 90% => 10% : +8% Current regulation +2% at the maximum current level Ripple voltage: Ripple voltage with standard battery capacity of 3x nominal current: without batteries 2.5% RMS typically (max 5%) with batteries 1% RMS Heat losses at rated power 393 W Long term stability for 1000 hours (of output voltage) 0.15% Charger characteristic per IEC 47810: IU High voltage insulation between input/output and electrical earth 2500V AC (With disconnected electronic boards in the rectifier). Insulation resistance with disconnected electronic boards in the Rectifier >200MΩ Input to ground 500V DC Input to output 500V DC Output to ground 500V DC Protection: • Slow start function • Short circuits • Limited at 100% of rated current • Internal DC fuse • Nonvolatile storage of system parameters and user settings • Mains failure shutdown, Rectifier failure shutdown • High voltage DC shutdown • History function for time stamped alarm and system events Battery adjustments (If battery is included in scope of supply, it must appear as a separate line in the quote) Manufacturer Enersys Type HX Capacity 47 Ah Number of cells 0 Number of strings 1 Float charge voltage 0,00 V High rate voltage 0,00 V High rate charge time (range 0150h): 4 h High rate charge timer mode settings Post Commissioning voltage 0,00 V End of discharge voltage 0,00 V Measurements – Alarms Measurements available on LCD display: • AC input voltage • DC charger voltage • DC charger current • DC battery current • Battery capacity • DC load voltage • DC load current Alarm indications: • Mains voltage alarm • Charge fault alarm • Battery voltage alarm • DC voltage alarm • Ground fault +/alarm • Charger current limit alarm • Battery current limit alarm • High charger current alarm • High battery current alarm • high temperature alarm • Temperature sensor error alarm • Internal communication error alarm • Battery test alarm • High battery temperature alarm • Long charge time alarm • No power supply voltage alarm • Battery in operation alarm • Service alarms List of installed items • EMI filter (CE) • Voltage temperature compensation (cable length 30m) • Bridge temperature alarm • AC input protection: Switch • Battery protection: Fuse • Load protection: None • Ground fault (by With GCAU) • Cabinet colour: RAL7035 • Cabinet protection degree: IP21
