EBT-1-240-400x150-GG-Pb82 - Tschan United States Sales

Please Contact Us to Order to offer best price and delivery time for Tschan - EBT-1-240-400x150-GG-Pb82 Ringfeder number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Tschan - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy EBT-1-240-400x150-GG-Pb82 by Tschan in United States?

You can purchase EBT-1-240-400x150-GG-Pb82 by Tschan from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the EBT-1-240-400x150-GG-Pb82?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Tschan in United States?

While we are not the official distributor or seller of Tschan in United States, we source our products from reliable channels and offer you original Tschan equipment at competitive prices.

How can I access EBT-1-240-400x150-GG-Pb82 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for EBT-1-240-400x150-GG-Pb82 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for EBT-1-240-400x150-GG-Pb82?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Technical specification

BRAND	Tschan
Product	EBT-1-240-400x150-GG-Pb82
Description	Ringfeder
Internal code	ONR4217861
Technical specification	Balancing according to DIN ISO 21940-11, balancing quality G6.3/1500 rpm consists of: Part 108 - braked side = gearbox side Bore diameter: Ø85H7, Bore chamfer: 3x45° 1 slot - DIN 6885/1, 22 P9x5,4+0,2 with adjusting screw M12, edge distance 35 Peel thread: M16 x 25 semi-wedge balanced Part 101 - Engine side Bore diameter: Ø98,425M7, Bore chamfer: 3x45° 1 Slot - USA Standard, 25.4 +0.07x9.57+0.25 with adjusting screw M12, edge distance 35 Peel thread: M16 x 25 semi-wedge balanced Brake Drum Ø400x150 EBT1 Total installation length L=244mm tKN: 3700 Nm (Pb82) TbR: 4200 Nm (braking torque /part 108 with brake drum 400x150 on the transmission side) Tkmax: 8650 Nm (Pb82) inch bore 3.875-INCH = METRIC 98.425mm According to the USA standard ANSI B17.1, there are two possibilities of groove shape: - Rectangular or, - Square
