Type: DRUF 19000 - Michael Riedel Transformatorenbau United States Sales

Please Contact Us to Order to offer best price and delivery time for Michael Riedel Transformatorenbau - Type: DRUF 19000 DX isolation transformer number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

default.not_official_distributor_Group5

Technical specification

BRAND	Michael Riedel Transformatorenbau
Product	Type: DRUF 19000
Description	DX isolation transformer
Internal code	ONR3820077
Weight	110
Custom code	85043300
Technical specification	Power: 19 kVA Primary voltage (PH-PH): 3AC 400 V (triangle) +PE Primary current: 27.5 A Secondary voltage (PH-PH): 3AC 230 V (star) +N Secondary current: 47.8 A Groupset: Dyn5 (N 100%) Design frequency: 50/60 Hz Protection class: SK I (protection class 1) Operating mode: S1 (continuous operation)/100% ED Ambient conditions: 40°C/F Type of cooling: ON (normal air convection) Installation height: 1000m above sea level Degree of protection: IPXXB (finger-safe) Primary connection: terminals (screw connection) for 6 mm² Secondary connection: terminals (screw connection) for 10 mm² Earth connection: terminals (screw connection) for 6 mm² Manufactured and tested according to: VDE 0570-2-4/EN61558-2-4 (isolating transformer) Offer 2022-1000780 Page 2 of 3 Item no. Unit Price Quantity Total PriceShipping Date Name Mechanical data: Dimensions (W x D x H): 420 x 195 x 420 mm Mounting dimensions (W x D): 316 x 158 mm, for M10
