MI-DM0080 DM0803-BAD1+H0E8GDG-200mm - Interroll United States Sales

Please Contact Us to Order to offer best price and delivery time for Interroll - MI-DM0080 DM0803-BAD1+H0E8GDG-200mm number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Interroll - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy MI-DM0080 DM0803-BAD1+H0E8GDG-200mm by Interroll in United States?

You can purchase MI-DM0080 DM0803-BAD1+H0E8GDG-200mm by Interroll from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the MI-DM0080 DM0803-BAD1+H0E8GDG-200mm?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Interroll in United States?

While we are not the official distributor or seller of Interroll in United States, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.

How can I access MI-DM0080 DM0803-BAD1+H0E8GDG-200mm catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MI-DM0080 DM0803-BAD1+H0E8GDG-200mm on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MI-DM0080 DM0803-BAD1+H0E8GDG-200mm?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Technical specification

BRAND	Interroll
Product	MI-DM0080 DM0803-BAD1+H0E8GDG-200mm
Internal code	ONR5000440
Technical specification	Product name DM 0080 3-phase asynchronous Vertical drum motor design Protection level IP 69K Tube length (SL) 193.0 mm Drum width (FW) 200.0 mm Installation length (EL/LW/BF) 229.0 mm Overall axle length (AGL) 254.0 mm Power 75 W coil number of pins 2 Torque [Nm] 6.5 Band tensile force 162 N Gear ratio (i) 26.94 Gear material name Steel: 16MnCr5/AISI 5115 Speed at frequency 1 0.42 m/s Frequency 1 50 Hz external connection diagram M34 high voltage 400 V low voltage 230 V Rated current, high voltage 0.27 A rated current, low voltage 0.46 A Speed at frequency 2 0.53 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Stainless steel pipe material: 1.4301/304 Pipe diameter (A) 81.0 mm Pipe diameter (B) 81.0 mm Cylindrical tube shape Cover A version Standard cover B version Standard Cover A Material stainless steel: 1.4301/304 Cover B Material stainless steel: 1.4301/304 Shaft A version special shaft with 1 surface Ø30 shaft B design special shaft with 1 surface Ø30 Shaft A Material stainless steel: 1.4305/303 Shaft B Material stainless steel: 1.4305/303 Shaft A diameter (D) 30.0 mm Shaft B diameter (D) 30.0 mm Wave A key area (F) 25.0 mm Wave B key area (F) 25.0 mm Wave A key face length (C) 12.5 mm Wave B key face length (C) 12.5 mm Oil type synthetic food oil Electrical connection straight screw connection Elek. Connection material stainless steel: 1.4301/304 Power cable length 1.0 m Power cable type shielded; not halogen-free
